These micropositioners are intended for probing applications in the testing and analysis of silicon wafers, substrates, and dies in the semiconductor industry. It provides 3-axis motion with .500" movement on each axis. Motion is controlled by three micrometer heads available with .01mm resolution. Precision high-quality 440 stainless steel ball bearings allow precise linear motion on all three axis. Gibs and Slides are made of 440 stainless steel. Slide bases are made of aluminum anodized black.
The XYZ 500 Micropositioner with micrometers is available also in a left hand and right hand model. A general purpose micropositioner, it is used for industrial, medical, biological, semiconductor, and general scientific applications. There are many front end options available to adapt to various testing applications. These translation stages are available in any combination of XYZ or just X and Y.
Specifications for XYZ 500 Micropositioner with Micrometers
Height: 4.00" Weight: Shipping weight less than 2 lb. Base footprint: 1.50" X 2.00" Travel: X, Y, Z axis = .500" Resolution: .01 mm per marking on the micrometers
Key Benefits
Available measurements in relative point to point moves
